| Motherboard |
|---|
| Motherboard form factor | NUC |
| Processor socket | BGA 2049 |
| Number of processors supported | 1 |
| Supported processor frequency (max) | 4.8 GHz |
| Processor |
|---|
| Thermal Design Power (TDP) | 28 W |
| L3 cache | 12 MB |
| Built-in processor | Yes |
| Processor model | 155H |
| Processor boost frequency | 4.8 GHz |
| Processor threads | 22 |
| Processor frequency | 1.4 GHz |
| Processor socket | BGA 2049 |
| Processor lithography | 7 nm |
| Processor cores | 16 |
| Processor family | Intel Core Ultra 7 |
| Number of processors supported | 1 |
| Supported processor frequency (max) | 4.8 GHz |
| L2 cache | 12 MB |
| Processor manufacturer | Intel |
| ECC supported by processor | No |
| Processor cache | 24 MB |
| Performance cores | 6 |
| Efficient cores | 8 |
| Performance-core Max Turbo Frequency | 4.8 GHz |
| Efficient-core Max Turbo Frequency | 3.8 GHz |
| Performance-core base frequency | 1.4 GHz |
| Efficient-core base frequency | 1 GHz |
| Low Power Efficient-cores | 2 |
| Low Power Efficient-core Base Frequency | 800 MHz |
| Memory |
|---|
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Memory channels | Dual-channel |
| Memory bandwidth (max) | 64 GB/s |
| ECC | No |
| Supported memory types | DDR5-SDRAM |
| Supported memory clock speeds | 5200 MHz |
| Maximum internal memory | 64 GB |
| Non-ECC | No |
| Storage |
|---|
| Supported storage drive types | SSD |
| Storage drive sizes supported | M.2 |
| Storage drive interface | PCI Express |
| Number of storage drives supported | 2 |
| Card reader integrated | No |
| NVMe | Yes |
| Audio |
|---|
| Intel® High Definition Audio (Intel® HD Audio) | Yes |
| Built-in speaker(s) | No |
| Network |
|---|
| Near Field Communication (NFC) | No |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Bluetooth version | 5.2 |
| Bluetooth | Yes |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| LAN controller | Intel I226-V |
| Bluetooth Low Energy (BLE) | Yes |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Ports & interfaces |
|---|
| Thunderbolt ports quantity | 2 |
| DC-in jack | No |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI version | 2.1 |
| VGA (D-Sub) ports quantity | 0 |
| USB 2.0 ports quantity | 0 |
| HDMI ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| Thunderbolt 4 ports quantity | 2 |
| Expansion slots |
|---|
| Number of M.2 (M) slots | 2 |
| Design |
|---|
| Motherboard form factor | NUC |
| VESA mounting | Yes |
| Product type | Mini PC barebone |
| On/off switch | Yes |
| Panel mounting interface | 100 x 100 mm |
| Cooling type | Passive |
| Product colour | Black |
| Chassis type | Cube |
| Performance |
|---|
| Motherboard form factor | NUC |
| Intel Visual BIOS | No |
| Intel Express BIOS update | No |
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Processor socket | BGA 2049 |
| Operating system installed | No |
| Number of processors supported | 1 |
| Supported processor frequency (max) | 4.8 GHz |
| Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
| Export Control Classification Number (ECCN) | 5A992.C |
| Processor special features |
|---|
| Intel Visual BIOS | No |
| Intel TSX-NI | No |
| Intel® Smart Response Technology | No |
| Intel Smart Connect Technology | No |
| Intel® Smart Cache | Yes |
| Intel® Small Business Advantage (Intel® SBA) | No |
| Intel® Secure Key | Yes |
| Intel® Matrix Storage Technology (Intel® MST) | No |
| Intel Express BIOS update | No |
| Intel® OS Guard | Yes |
| Intel Stable Image Platform Program (SIPP) | No |
| Thermal Monitoring Technologies | Yes |
| Intel® Wireless Display (Intel® WiDi) | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Turbo Boost Technology | Yes |
| Intel Trusted Execution Technology | No |
| Intel® Quick Sync Video Technology | Yes |
| Intel® My WiFi Technology (Intel® MWT) | No |
| Intel® InTru™ 3D Technology | No |
| Intel® Insider™ | No |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel Flex Memory Access | Yes |
| Intel FDI Technology | No |
| Intel Fast Memory Access | No |
| Intel Demand Based Switching | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel 64 | Yes |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® Rapid Start Technology | No |
| Intel Advanced Management Technology | No |
| Conflict-Free | Yes |
| Intel Clear Video Technology | Yes |
| Intel® Unite™ | No |
| Intel Unite installed | No |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Optane™ Memory Ready | No |
| Intel® Virtualization Technology (Intel® VT) | Yes |
| Intel Rapid Storage Technology | Yes |
| Intel® High Definition Audio (Intel® HD Audio) | Yes |
| Intel Dual Display Capable Technology | Yes |
| Embedded options available | No |
| Intel On-Demand Power Redundancy Technology | No |
| Intel® Platform Trust Technology (Intel® PTT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel® vPro™ Platform Eligibility | No |
| Low Power Efficient-cores | 2 |
| Low Power Efficient-core Base Frequency | 800 MHz |
| Colour |
|---|
| Product colour | Black |
| Technical details |
|---|
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Virtualization Technology (Intel® VT) | Yes |
| Intel Rapid Storage Technology | Yes |
| Intel® High Definition Audio (Intel® HD Audio) | Yes |
| Intel Dual Display Capable Technology | Yes |
| Embedded options available | No |
| Panel mounting interface | 100 x 100 mm |
| Trusted Platform Module (TPM) version | 2.0 |
| Quick start guide | No |
| Processor cores | 16 |
| Intel On-Demand Power Redundancy Technology | No |
| Cooling type | Passive |
| Chassis type | Cube |
| Introduction year | 2025 |
| Introduction month | June |
| Warranty period | 3 year(s) |
| PSTI certified | No |
| Not classified as hazardous under GHS | No |
| Packaging data |
|---|
| Power cord included | Yes |
| Drivers included | No |
| AC adapter included | No |
| Package width | 205 mm |
| Package depth | 220 mm |
| Package height | 94 mm |
| Certificates |
|---|
| Waste Electrical and Electronic Equipment (WEEE) compliance | Yes |
| Software |
|---|
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Operating system installed | No |
| Management features |
|---|
| On/off switch | Yes |
| Logistics data |
|---|
| Country of origin | China |
| Certification |
|---|
| Waste Electrical and Electronic Equipment (WEEE) compliance | Yes |
| Power |
|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power supply type | External AC adapter |
| Power supply | 120 W |
| Number of power supply units | 1 |
| Operational conditions |
|---|
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 0 - 90% |
| Operating temperature (T-T) | 0 - 35 °C |
| Operating relative humidity (H-H) | 0 - 85% |
| Weight & dimensions |
|---|
| Width | 119.6 mm |
| Depth | 115.2 mm |
| Height | 37.5 mm |
| Package width | 205 mm |
| Package depth | 220 mm |
| Package height | 94 mm |
| Packaging content |
|---|
| Display included | No |
| Power cord included | Yes |
| Drivers included | No |
| AC adapter included | No |
| Mouse included | No |
| Quick start guide | No |
| Keyboard included | No |
| Other features |
|---|
| Embedded options available | No |
| Chassis type | Cube |
| Country of origin | China |
| Introduction year | 2025 |
| Introduction month | June |
| Warranty period | 3 year(s) |
