Scanning |
---|
Maximum scan size | 216 x 3100 mm |
Optical scanning resolution | 600 x 600 DPI |
Colour scanning | Yes |
Duplex scanning | Yes |
Input colour depth | 24 bit |
Output colour depth | 24 bit |
Film scanning | No |
Greyscale levels | 256 |
ADF scan speed (b/w, A4) | 75 ppm |
ADF scan speed (colour, A4) | 75 ppm |
Sensor type | CMOS CIS |
Scan file formats | BMP, JPG, PDF, PNG, RTF, TIFF, TXT, XLS, XML, XPS |
Daily duty cycle (max) | 7500 pages |
Design |
---|
Built-in display | Yes |
Scanner type | Sheet-fed scanner |
Display | LCD |
Product colour | White |
Performance |
---|
Sensor type | CMOS CIS |
Scan file formats | BMP, JPG, PDF, PNG, RTF, TIFF, TXT, XLS, XML, XPS |
Daily duty cycle (max) | 7500 pages |
Scan drivers | TWAIN, WIA |
Internal memory | 512 MB |
Built-in processor | Yes |
Input capacity |
---|
Auto document feeder (ADF) input capacity | 80 sheets |
Paper handling |
---|
Maximum ISO A-series paper size | A4 |
ISO B-series sizes (B0...B9) | B5 |
ISO A-series sizes (A0...A9) | A4, A5, A6, A7, A8 |
Ports & interfaces |
---|
Standard interfaces | USB 2.0, USB 3.2 Gen 1 (3.1 Gen 1) |
USB port | Yes |
USB version | 3.2 Gen 1 (3.1 Gen 1) |
Software |
---|
Windows operating systems supported | Windows 11, Windows 10, Windows 8, Windows 7 |
Mac operating systems supported | Mac OS X 10.11 El Capitan |
Bundled software | HP WIA scan driver, HP TWAIN scan driver (32-bit and 64-bit), HP Scan Premium, HP Scanner Tools Utility, EMC ISIS driver, Kofax VRS Pro |
Scan drivers | TWAIN, WIA |
Power |
---|
Power consumption (off) | 0.1 W |
Input voltage | 90-264 V |
Power supply type | AC |
AC input frequency | 50 - 60 Hz |
Operational conditions |
---|
Non-operating relative humidity (non-condensing) | 0 - 90% |
Operating temperature (T-T) | 10 - 35 °C |
Storage temperature (T-T) | -40 - 60 °C |
Operating relative humidity (H-H) | 15 - 80% |
System requirements |
---|
Recommended system requirements | Microsoft® Windows® 10, 8.1, 8, 7, XP: 32/64-bit, 2 GB available hard disk space, CD-ROM/DVD drive or Internet connection, USB port, Microsoft® Internet Explorer; Windows Vista®: 32-bit only, 2 GB available hard disk space, CD-ROM/DVD drive or Internet connection, USB port, Microsoft® Internet Explorer 8 |
Windows operating systems supported | Windows 11, Windows 10, Windows 8, Windows 7 |
Mac operating systems supported | Mac OS X 10.11 El Capitan |
Weight & dimensions |
---|
Width | 310 mm |
Depth | 198 mm |
Height | 190 mm |
Weight | 3.8 kg |
Package depth | 248 mm |
Package weight | 5.4 kg |
Package width | 397 mm |
Package height | 303 mm |
Packaging data |
---|
Package depth | 248 mm |
Package weight | 5.4 kg |
Package width | 397 mm |
Package height | 303 mm |
Packaging content |
---|
Cables included | AC, USB |
Bundled software | HP WIA scan driver, HP TWAIN scan driver (32-bit and 64-bit), HP Scan Premium, HP Scanner Tools Utility, EMC ISIS driver, Kofax VRS Pro |
Warranty card | Yes |
Processor |
---|
Built-in processor | Yes |
Memory |
---|
Internal memory | 512 MB |
Display |
---|
Display | LCD |
Media formats |
---|
ISO B-series sizes (B0...B9) | B5 |
ISO A-series sizes (A0...A9) | A4, A5, A6, A7, A8 |
Features |
---|
Country of origin | China |
Sustainability |
---|
Sustainability compliance | Yes |
Sustainability certificates | ENERGY STAR |
Technical details |
---|
Scanner type | Sheet-fed scanner |
Image formats supported | BMP, JPEG, PNG, TIFF |
Country of origin | China |
Product colour | White |
Sustainability compliance | Yes |
Sustainability certificates | ENERGY STAR |
Master (outer) cases per pallet layer | 12 pc(s) |
Harmonized System (HS) code | 8471608000 |
Certificates |
---|
Certification | Class B Emissions; CISPR 22:2008 (International); European Union EMC Directive 2004/108/EC, EN 55022:2010 (CE mark); EAC EMC Certificate; Ukraine EMC approval; EN 61000-3-2:2014 (harmonics); EN 61000-3-3:2013 (flicker); Immunity CISPR 24:2010, EN 50024:2010 |
Other features |
---|
Image formats supported | BMP, JPEG, PNG, TIFF |
Certification | Class B Emissions; CISPR 22:2008 (International); European Union EMC Directive 2004/108/EC, EN 55022:2010 (CE mark); EAC EMC Certificate; Ukraine EMC approval; EN 61000-3-2:2014 (harmonics); EN 61000-3-3:2013 (flicker); Immunity CISPR 24:2010, EN 50024:2010 |
Non-operating relative humidity (non-condensing) | 0 - 90% |
Recommended system requirements | Microsoft® Windows® 10, 8.1, 8, 7, XP: 32/64-bit, 2 GB available hard disk space, CD-ROM/DVD drive or Internet connection, USB port, Microsoft® Internet Explorer; Windows Vista®: 32-bit only, 2 GB available hard disk space, CD-ROM/DVD drive or Internet connection, USB port, Microsoft® Internet Explorer 8 |
Scanner type | Sheet-fed scanner |
Country of origin | China |
Logistics data |
---|
Country of origin | China |
Master (outer) cases per pallet layer | 12 pc(s) |
Harmonized System (HS) code | 8471608000 |
