Performance |
---|
Preset points | Yes |
Infrared (IR) cut-off filter | Yes |
Number of languages | 19 |
Languages support | Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese |
Processor model | ARTPEC-8 |
PTZ modes | Digital PTZ |
Type | IP security camera |
Connectivity technology | Wired |
PTZ control | Yes |
Placement supported | Outdoor |
Wide Dynamic Range (WDR) | Yes |
Day/night mode | Yes |
Design |
---|
IK code | IK10 |
Form factor | Dome |
Product colour | White |
Mounting type | Wall/Pole |
International Protection (IP) code | IP66 |
Housing material | Aluminium, Polycarbonate (PC) |
Camera |
---|
Minimum illumination | 0.07 lx |
Tilt angle range | -8 - 75° |
Pan range | 0 - 190° |
Camera shutter speed | 1/66500 - 2 s |
Camera pan control | Yes |
Camera tilt control | Yes |
Lens viewing angle, horizontal | 103 – 48 |
Lens viewing angle, vertical | 56.4 - 27.4° |
Progressive scan | Yes |
Image sensor |
---|
Sensor type | CMOS |
Progressive scan | Yes |
Optical sensor size | 25.4 / 1.2 mm (1 / 1.2") |
Number of sensors | 1 |
Panoramic camera |
---|
Signal-to-Noise Ratio (SNR) (panoramic camera) | 55 dB |
Lens system |
---|
Maximum aperture number | 2.9 |
Minimum aperture number | 1.6 |
Focal length range | 6.2–12.9 |
Night vision |
---|
Night vision | Yes |
Video |
---|
Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
Text caption overlay | Yes |
Privacy masking | Yes |
Image stabilizer | Yes |
Video compression formats | H.264, H.265, M-JPEG |
Maximum resolution | 3840 x 2160 pixels |
Supported graphics resolutions | 160 x 120, 160 x 90, 1280 x 800, 2880 x 2160, 3840 x 2160 |
Frame rate | 30 fps |
Video streaming | Yes |
Total megapixels | 8 MP |
Audio |
---|
Voice codecs | AGC |
Sample rate | 48 kHz |
Audio system full duplex | Yes |
Audio system | 2-way |
Audio formats supported | AAC-LC, ADPCM, G.711, G.726, LPCM, OPUS |
Audio detection | Yes |
Network |
---|
Bluetooth | No |
Networking standards | IEEE 802.3at |
Quality of Service (QoS) support | Yes |
Ethernet LAN | Yes |
Wi-Fi | No |
Supported network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSb , HTTP/2, TLSb , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf), IEEE 802.1X (EAP-TLS), IEEE 802.1AR |
Storage |
---|
Card reader integrated | Yes |
Built-in HDD | No |
Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD |
Internal memory | 2048 MB |
Flash memory | 8192 MB |
Ports & interfaces |
---|
Terminal block port | Yes |
Microphone in | Yes |
Ethernet LAN (RJ-45) ports | 1 |
DC-in jack | Yes |
Connectivity technology | Wired |
Security |
---|
Alert notification type | E-mail |
Video motion detection | Yes |
IP address filtering | Yes |
HTTPS encryption | Yes |
Password protection | Yes |
Pixel counter | Yes |
Digest authentication | Yes |
Power |
---|
Power source type | DC, PoE |
Power consumption (max) | 25 W |
Power consumption (typical) | 8 W |
DC-in jack | Yes |
DC output voltage | 10, 28 |
Sustainability |
---|
Sustainability compliance | Yes |
Compliance certificates | CE, KC, REACH, RoHS, UKCA |
Packaging content |
---|
Number of cameras | 1 |
Screws included | Yes |
Mounting brackets included | Yes |
Manual | Yes |
Technical details |
---|
Sustainability compliance | Yes |
Doesn't contain | BFR, PVC |
Compliance certificates | CE, KC, REACH, RoHS, UKCA |
Other features |
---|
Video compression formats | H.264, H.265, M-JPEG |
Doesn't contain | BFR, PVC |
