| Performance |
|---|
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Dynamic range | 120 dB |
| Design |
|---|
| IK code | IK10 |
| Form factor | Bullet |
| Product colour | Grey |
| Mounting type | Ceiling/Wall/Pole |
| International Protection (IP) code | IP66 |
| Housing material | Aluminium |
| Camera |
|---|
| Minimum illumination | 0 lx |
| White balance | ATW, AWC, Indoor, Manual, Outdoor |
| Camera shutter type | Electronic |
| Camera shutter speed | 1/5~1/12,000 s |
| Lens viewing angle, horizontal | 49° |
| Lens viewing angle, vertical | 27.6° |
| Lens viewing angle, diagonal | 55.6° |
| Image sensor |
|---|
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 3 mm (1 / 3") |
| Number of sensors | 1 |
| Panoramic camera |
|---|
| Recognize distance (wide) (panoramic camera) | 22.5 m |
| Observe distance (wide) (panoramic camera) | 44.9 m |
| Maximum aperture number (panoramic camera) | 2 |
| Identify distance (wide) (panoramic camera) | 11.2 m |
| Focal length range (panoramic camera) | 6 mm |
| Detect distance (wide) (panoramic camera) | 112.3 m |
| Lens system |
|---|
| Number of lenses | 1 |
| Maximum aperture number | 2 |
| Detect distance | 112.3 m |
| Observe distance | 44.9 m |
| Recognize distance | 22.5 m |
| Identify distance | 11.2 m |
| Fixed focus | Yes |
| Fixed focal length | 6 mm |
| Night vision |
|---|
| Night vision | Yes |
| Video |
|---|
| Noise reduction | Yes |
| Privacy masking | Yes |
| Gain control type | Auto/Manual |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Back Light Compensation (BLC) | Yes |
| Video compression formats | H.264, H.265, M-JPEG |
| Maximum resolution | 2560 x 1440 pixels |
| Video formats supported | H.264, H.265, M-JPEG |
| Supported graphics resolutions | 320 x 240, 640 x 360, 640 x 480 (VGA), 720 x 480, 720 x 576, 800 x 448, 800 x 600 (SVGA), 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2560 x 1440 |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Total megapixels | 4 MP |
| Audio |
|---|
| Audio input channels | 1.0 channels |
| Audio formats supported | G.711 μ-law, G.726 |
| Network |
|---|
| Bluetooth | No |
| Ethernet interface type | Gigabit Ethernet |
| Networking standards | IEEE 802.1x |
| Number of users | 6 user(s) |
| Streaming method | Multicast, Unicast |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP |
| Storage |
|---|
| ROM capacity | 512 MB |
| Maximum memory card size | 128 GB |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Flash memory | 256 MB |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Alert notification type | E-mail |
| Intelligent Video Surveillance (IVS) system features | Covering detection, Defocus |
| Video motion detection | Yes |
| IP address filtering | Yes |
| Digest authentication | Yes |
| Alarm input channels | 1 |
| Alarm output channels | 1 |
| Power |
|---|
| Power source type | DC, PoE |
| Power consumption (max) | 9.1 W |
| Power consumption (Power over Ethernet (PoE)) | 10.7 W |
| Power consumption (typical) | 6.8 W |
| Operational conditions |
|---|
| Operating temperature (T-T) | -40 - 55 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions |
|---|
| Height | 246 mm |
| Diameter | 7 cm |
| Weight | 700 g |
| Packaging content |
|---|
| Number of cameras | 1 |
| Other features |
|---|
| Video compression formats | H.264, H.265, M-JPEG |
