| Processor |
|---|
| Thermal Design Power (TDP) | 65 W |
| Processor threads | 12 |
| Memory types supported by processor | DDR5-SDRAM |
| Memory clock speeds supported by processor | 4800 MHz |
| Processor cache | 18 MB |
| Processor frequency | 3.1 GHz |
| Processor boost frequency | 5.2 GHz |
| Number of processors installed | 1 |
| Processor model | 6333P |
| System bus rate | 16 GT/s |
| Processor manufacturer | Intel |
| Processor family | Intel Xeon 6 |
| Performance cores | 6 |
| Memory |
|---|
| Internal memory | 16 GB |
| Memory layout (slots x size) | 1 x 16 GB |
| Memory slots | 4x DIMM |
| Maximum internal memory | 128 GB |
| Internal memory type | DDR5-SDRAM |
| ECC | Yes |
| Memory data transfer rate | 5600 MT/s |
| Buffered memory type | Unregistered (unbuffered) |
| Storage |
|---|
| Supported RAID controllers | PERC H355 Adapter LP |
| Number of SSDs supported | 6 |
| Total storage capacity | 480 GB |
| SSD interface | SATA III |
| SSD capacity | 480 GB |
| RAID support | No |
| Optical drive type | No |
| Number of SSDs installed | 1 |
| Hot-Plug support | Yes |
| SSD size | 2.5" |
| Drive writes per day (DWPD) | 1 |
| Supported SSD sizes | 2.5" |
| Graphics |
|---|
| Thermal Design Power (TDP) | 65 W |
| Network |
|---|
| LAN controller | Broadcom 5720 |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Cabling technology | 10/100/1000Base-T(X) |
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| USB 2.0 ports quantity | 2 |
| Serial ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Optical drive |
|---|
| Optical drive type | No |
| Design |
|---|
| Optical drive type | No |
| Chassis type | Rack (1U) |
| Product colour | Black |
| Bezel | Yes |
| Performance |
|---|
| Compatible operating systems | Canonical Ubuntu Server LTS Microsoft Windows Server with Hyper-V Red Hat Enterprise Linux SUSE Linux Enterprise Server VMware ESXi |
| Remote administration | iDRAC9, Enterprise 16G |
| Trusted Platform Module (TPM) | Yes |
| Operating system installed | No |
| Software |
|---|
| Compatible operating systems | Canonical Ubuntu Server LTS Microsoft Windows Server with Hyper-V Red Hat Enterprise Linux SUSE Linux Enterprise Server VMware ESXi |
| Operating system installed | No |
| Power |
|---|
| Number of main power supplies | 1 |
| Redundant power supply (RPS) support | No |
| Power supply | 700 W |
| Power cable length | 2 m |
| Power cable connector 1 | C13 coupler |
| Power cable connector 2 | C14 coupler |
| Power cable current | 10 A |
| Power supply input voltage | 200 - 240 V |
| Operational conditions |
|---|
| Storage temperature (T-T) | -40 - 65 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 3048 m |
| Non-operating altitude | 0 - 12000 m |
| Certificates |
|---|
| 80 PLUS certification | 80 PLUS Titanium |
| Management features |
|---|
| Remote administration | iDRAC9, Enterprise 16G |
| Sustainability |
|---|
| Total carbon footprint (kg of CO2e) | 950 |
| Carbon footprint |
|---|
| Total carbon footprint (kg of CO2e) | 950 |
| Total carbon emissions, standard deviation (kg of CO2e) | 711 |
| PAIA version | 1.3.2, 2024 |
| Carbon emissions, energy usage (kg of CO2e) | 541.5 |
| Carbon emissions, manufacturing (kg of CO2e) | 304 |
| Carbon emissions, logistics (kg of CO2e) | 95 |
| Carbon emissions, end-of-life (kg of CO2e) | 9.5 |
| Technical details |
|---|
| Trusted Platform Module (TPM) | Yes |
| Hot-Plug support | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Chassis type | Rack (1U) |
| Packaging content | 1U/2U 2/4-Post Static Rails,Riser Config 1, Gen4 Riser |
| Weight & dimensions |
|---|
| Width | 482 mm |
| Height | 42.8 mm |
| Packaging content |
|---|
| Packaging content | 1U/2U 2/4-Post Static Rails,Riser Config 1, Gen4 Riser |
| Other features |
|---|
| Data transfer rate | 6 Gbit/s |
| Bytes per sector | 512e |
| Target workload | Read Intensive (RI) |
