| Processor |
|---|
| Processor cache type | L3 |
| Processor cache | 48 MB |
| Processor frequency | 2.2 GHz |
| Processor boost frequency | 4.1 GHz |
| Number of processors installed | 1 |
| Processor model | 6505P |
| Processor cores | 12 |
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® |
| Memory |
|---|
| Internal memory | 64 GB |
| Memory layout (slots x size) | 2 x 32 GB |
| Memory slots | 32x DIMM |
| Memory clock speed | 6400 MHz |
| Maximum internal memory | 8 TB |
| Internal memory type | DDR5-SDRAM |
| Storage |
|---|
| Supported RAID controllers | HPE MR416i-o Gen11 x16 Lanes 8GB Cache OCP SPDM Storage Controller |
| Total storage capacity | 16 TB |
| Number of HDDs installed | 2 |
| HDD speed | 7200 RPM |
| HDD capacity | 8 TB |
| RAID support | Yes |
| Optical drive type | No |
| Number of HDDs supported | 12 |
| HDD size | 3.5" |
| HDD interface | Serial Attached SCSI (SAS) |
| Storage drive type | 2x HPE 8TB SAS 12G Business Critical 7.2K LFF LP 1-year Warranty 512e Multi Vendor HDD |
| Graphics |
|---|
| On-board graphics card model | Not available |
| On-board graphics card | No |
| Network |
|---|
| LAN controller | Broadcom BCM5719 |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| VGA (D-Sub) ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 4 |
| Expansion slots | Up to 8 PCIe Gen5, and 2 OCP 3.0 (front or rear), for detailed descriptions reference the QuickSpecs |
| Number of management ports | 1 pc(s) |
| Optical drive |
|---|
| Optical drive type | No |
| Design |
|---|
| Optical drive type | No |
| Chassis type | Rack (2U) |
| Product colour | Black, Silver |
| Cooling type | Active |
| Performance |
|---|
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
| Security features | HPE TPM 2.0 standard on motherboard. Optional locking Bezel Kit, Intrusion Detection Kit. For full security features refer to the QuickSpecs. |
| Operating system installed | No |
| Management platform | HPE iLO Standard with intelligent provisioning (embedded), HPE OneView Standard (requires download) (standard) HPE iLO Advanced, HPE OneView Advanced (optional, requires licenses), and HPE Compute Ops Management (optional subscription available). Refer to the iLO 7 User Guide |
| Software |
|---|
| Operating system installed | No |
| Power |
|---|
| Number of main power supplies | 2 |
| Power supply type | 2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit |
| Redundant power supply (RPS) support | Yes |
| Power supply | 1000 W |
| Management features |
|---|
| Management platform | HPE iLO Standard with intelligent provisioning (embedded), HPE OneView Standard (requires download) (standard) HPE iLO Advanced, HPE OneView Advanced (optional, requires licenses), and HPE Compute Ops Management (optional subscription available). Refer to the iLO 7 User Guide |
| Technical details |
|---|
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
| Security features | HPE TPM 2.0 standard on motherboard. Optional locking Bezel Kit, Intrusion Detection Kit. For full security features refer to the QuickSpecs. |
| Number of processors supported | 1 |
| Ethernet interface type | Gigabit Ethernet |
| Chassis type | Rack (2U) |
| Standard fans | 6x Standard Fans |
| Weight & dimensions |
|---|
| Width | 727 mm |
| Height | 87.5 mm |
| Depth | 448 mm |
| Other features |
|---|
| Security features | HPE TPM 2.0 standard on motherboard. Optional locking Bezel Kit, Intrusion Detection Kit. For full security features refer to the QuickSpecs. |
| Number of processors supported | 1 |
| Standard fans | 6x Standard Fans |
| Storage drive type | 2x HPE 8TB SAS 12G Business Critical 7.2K LFF LP 1-year Warranty 512e Multi Vendor HDD |
