| Display |
|---|
| LED backlighting type | Direct-LED |
| Touchscreen | No |
| Active display area (W x H) | 941.184 x 529.416 mm |
| Display technology | LED |
| Colour gamut | 72% |
| Display diagonal | 108 cm (42.5") |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 500 cd/m² |
| HD type | 4K Ultra HD |
| Response time | 6.5 ms |
| Contrast ratio (typical) | 5000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Pixel pitch | 0.2451 x 0.2451 mm |
| Colour depth | 8 bit |
| Native refresh rate | 60 Hz |
| Ports & interfaces |
|---|
| USB port | Yes |
| Wi-Fi | Yes |
| PC Audio out | Yes |
| PC Audio in | Yes |
| DisplayPorts quantity | 0 |
| Compatible memory cards | MicroSD (TransFlash) |
| Card reader integrated | Yes |
| Ethernet LAN | Yes |
| HDMI ports quantity | 2 |
| DVI port | No |
| VGA (D-Sub) input ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB ports quantity | 2 |
| HDMI input ports quantity | 2 |
| Audio |
|---|
| Number of built-in speakers | 2 |
| RMS rated power | 5 W |
| Built-in speaker(s) | Yes |
| Speaker impedance | 8 Ω |
| Design |
|---|
| Product design | Kiosk design |
| Placement supported | Indoor |
| Orientation | Vertical |
| Product colour | Black |
| Mounting type | Floor |
| Performance |
|---|
| Purpose | Commercial |
| Operating hours (hours/days) | 24/7 |
| Wi-Fi | Yes |
| Power |
|---|
| Power consumption (typical) | 150 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Energy efficiency scale | A to G |
| Energy efficiency class (SDR) | G |
| Energy consumption (SDR) per 1000 hours | 54 kWh |
| Computer system |
|---|
| Computer system | No |
| Processor cores | 4 |
| Processor family | ARM Cortex |
| Processor model | A17 |
| Processor frequency | 1.6 GHz |
| Operating system installed | Android 8.1 |
| Internal memory | 2 GB |
| Internal storage capacity | 16 GB |
| Video formats supported | 3GP, ASF, AVI, DAT, DIVX WEBM, FLV, MKV, MOV, MP4, MPG, TS, VOB, WMA |
| Audio formats supported | 3GP, FLAC, IMY, M4A, MP1, MP2, MP3, OGG, RTTTL, RTX, WAV, WMA, XMF |
| Image formats supported | BMP, GIF, JPEG, JPG, PNG |
| Processor manufacturer | ARM |
| Built-in processor | Yes |
| Weight & dimensions |
|---|
| Width (with stand) | 585.1 mm |
| Height (with stand) | 1767.3 mm |
| Depth (with stand) | 450 mm |
| Weight | 48.5 kg |
| Weight (with stand) | 63.5 kg |
| Display width | 585.1 mm |
| Display depth | 55 mm |
| Display height | 1705.8 mm |
| Packaging content |
|---|
| Stand included | Yes |
| Mounting kit | Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Storage relative humidity (H-H) | 5 - 90% |
| Thin Client |
|---|
| Processor family | ARM Cortex |
| Processor model | A17 |
| Processor frequency | 1.6 GHz |
| Operating system installed | Android 8.1 |
| Internal memory | 2 GB |
| Internal storage capacity | 16 GB |
| Video formats supported | 3GP, ASF, AVI, DAT, DIVX WEBM, FLV, MKV, MOV, MP4, MPG, TS, VOB, WMA |
| Audio formats supported | 3GP, FLAC, IMY, M4A, MP1, MP2, MP3, OGG, RTTTL, RTX, WAV, WMA, XMF |
| Image formats supported | BMP, GIF, JPEG, JPG, PNG |
| Packaging data |
|---|
| Mounting kit | Yes |
| Features |
|---|
| Base colour | Black |
| Technical details |
|---|
| Stand included | Yes |
| LED backlighting type | Direct-LED |
| Weight (with stand) | 63.5 kg |
| Other features |
|---|
| Stand included | Yes |
| Wi-Fi | Yes |
| Width (with stand) | 585.1 mm |
| PC Audio out | Yes |
| Height (with stand) | 1767.3 mm |
| Display technology | LED |
| Depth (with stand) | 450 mm |
| Compatible memory cards | MicroSD (TransFlash) |
| Card reader integrated | Yes |
| Bluetooth version | 4.2 |
| Bluetooth | Yes |
| Weight (with stand) | 63.5 kg |
| Energy efficiency scale | A to G |
