| Display |
|---|
| LED backlight | Yes |
| Display number of colours | 1.07 billion colours |
| LED backlighting type | Edge-LED |
| Touchscreen | No |
| Active display area (W x H) | 1209.6 x 691.89 mm |
| Display technology | LED |
| Colour gamut | 85% |
| Display diagonal | 139.7 cm (55") |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 500 cd/m² |
| HD type | 4K Ultra HD |
| Response time | 8 ms |
| Contrast ratio (typical) | 5000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Pixel pitch | 0.315 x 0.315 mm |
| Native aspect ratio | 16:9 |
| Colour depth | 10 bit |
| Native refresh rate | 60 Hz |
| RGB colour space | NTSC |
| Ports & interfaces |
|---|
| USB port | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Wi-Fi | Yes |
| PC Audio out | Yes |
| DisplayPorts quantity | 1 |
| Compatible memory cards | MicroSD (TransFlash) |
| Card reader integrated | Yes |
| Ethernet LAN | Yes |
| HDMI ports quantity | 3 |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-232 interface | Yes |
| USB version | 2.0 |
| USB ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Audio |
|---|
| Number of built-in speakers | 2 |
| RMS rated power | 20 W |
| Built-in speaker(s) | Yes |
| Design |
|---|
| Product design | Digital signage flat panel |
| Placement supported | Indoor |
| Orientation | Horizontal |
| Product colour | Grey |
| VESA mounting | Yes |
| Screen shape | Flat |
| Wall mountable | Yes |
| Performance |
|---|
| Purpose | Commercial |
| Operating hours (hours/days) | 24/7 |
| Wi-Fi | Yes |
| Power |
|---|
| Power consumption (max) | 140 W |
| Power consumption (typical) | 75 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Energy efficiency class (SDR) | F |
| Energy efficiency class (HDR) | Not available |
| Computer system |
|---|
| Computer system | Yes |
| Computer system type | System on Chip (SoC) |
| Processor cores | 4 |
| Processor family | ARM Cortex |
| Processor model | A55 |
| Processor frequency | 1.92 GHz |
| Internal memory | 4 GB |
| Internal storage capacity | 32 GB |
| Video formats supported | 3GP, ASF, AVI, DAT, MKV, MOV, MP4, MPG, TS, VOB |
| Audio formats supported | FLAC, IMY, M4A, MP1, MP2, MP3, MXMF, OGA, OGG, OTA, RTTTL, RTX, WAV, WMA, XMF |
| Image formats supported | BMP, GIF, JPEG, JPG, PNG |
| Processor manufacturer | ARM |
| Built-in processor | Yes |
| Processor architecture | ARM Cortex-A55 |
| Weight & dimensions |
|---|
| Display width | 1239.7 mm |
| Display depth | 38.6 mm |
| Display height | 712.5 mm |
| Display weight | 17.6 kg |
| Packaging data |
|---|
| Package width | 1390 mm |
| Package depth | 136 mm |
| Package height | 850 mm |
| Package weight | 24 kg |
| Quick start guide | Yes |
| Remote control included | Yes |
| Mounting kit | Yes |
| Cables included | AC, RS-232 |
| Packaging content |
|---|
| Quick start guide | Yes |
| Remote control included | Yes |
| Mounting kit | Yes |
| Cables included | AC, RS-232 |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Technical details |
|---|
| VESA mounting | Yes |
| Power supply type | Internal |
| LED backlighting type | Edge-LED |
| Network |
|---|
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
| Thin Client |
|---|
| Processor family | ARM Cortex |
| Processor model | A55 |
| Processor frequency | 1.92 GHz |
| Internal memory | 4 GB |
| Internal storage capacity | 32 GB |
| Video formats supported | 3GP, ASF, AVI, DAT, MKV, MOV, MP4, MPG, TS, VOB |
| Audio formats supported | FLAC, IMY, M4A, MP1, MP2, MP3, MXMF, OGA, OGG, OTA, RTTTL, RTX, WAV, WMA, XMF |
| Image formats supported | BMP, GIF, JPEG, JPG, PNG |
| Features |
|---|
| Wall mountable | Yes |
| Other features |
|---|
| Power supply type | Internal |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Wi-Fi | Yes |
| Power cord included | Yes |
| Power consumption (max) | 140 W |
| PC Audio out | Yes |
| Display technology | LED |
| Compatible memory cards | MicroSD (TransFlash) |
| Card reader integrated | Yes |
| Bluetooth version | 5.0 |
| Bluetooth | Yes |
| Quick start guide | Yes |
