SKU: 1USB3-NVME-DOCK  |   Brand: StarTech.com

StarTech.com USB-C/USB-A to M.2 NVMe Dock Adapter, 10Gbps, Tool-Free External M.2 NVMe SSD Reader, B+M/M-Key

SKU: 1USB3-NVME-DOCK  |   Brand: StarTech.com

StarTech.com USB-C/USB-A to M.2 NVMe Dock Adapter, 10Gbps, Tool-Free External M.2 NVMe SSD Reader, B+M/M-Key

44 in stock

£28.57 ex. VAT

Figures are exclusive of VAT.



Access Ultra-Fast M.2 NVMe drive storage via USB 10Gbps

Access and manage M.2 NVMe SSDs through a single USB-C or USB-A 10Gbps connection. The M.2 NVMe SSD Dock enables fast read and write access for data transfer, recovery, and upgrades. This drive reader is a versatile solution for IT professionals performing backups, disk imaging, or maintenance on M.2 NVMe drives.

External Drive Access over USB-C and USB-A

Connect the M.2 NVMe Dock directly to a laptop or workstation using the integrated USB-C cable with USB-A adapter. The open-top, toaster-style M.2 slot maintains airflow for consistent performance during sustained workloads and provides ample clearance to support NVMe drives with attached heatsinks. The NVMe adapter supports read/write speeds of up to 10Gbps. Please note that M.2 SATA drives are not supported.

Compact Form Factor

Lightweight and portable, the USB-C/USB-A to M.2 NVMe Dock Adapter fits easily into any IT toolkit or workspace. The enclosure is constructed from 70% post-consumer recycled (PCR) plastic with a 35% PCR TPE jacket, and is packaged in 100% plastic-free FSC certified packaging to help reduce material waste. It runs entirely on USB bus power, requiring no external power adapter. Ideal for IT technicians and end users needing portable, fast M.2 NVMe drive access.

Storage media type SSD
Storage drive interface M.2
Storage drive sizes supported M.2 "
Weight 109.00kg

Hard drive
Storage media typeSSD
Storage drive interfaceM.2
Storage drive sizes supportedM.2
Number of storage drives supported1
Ports & interfaces
Host interfaceUSB 3.2 Gen 2 (3.1 Gen 2) Type-C
Technical details
UASP supportYes
Mean time between failures (MTBF)129956 h
Package width152 mm
Package height30 mm
Maximum data transfer rate10 Gbit/s
Product colourBlack
Hot-swapYes
ChipsetASMedia - ASM2362
TRIM supportYes
S.M.A.R.T. supportYes
Features
UASP supportYes
Mean time between failures (MTBF)129956 h
Maximum data transfer rate10 Gbit/s
LED indicatorsYes
Product colourBlack
Hot-swapYes
ChipsetASMedia - ASM2362
TRIM supportYes
S.M.A.R.T. supportYes
Cooling
Built-in fanNo
Weight & dimensions
Width59 mm
Depth403.7 mm
Height18 mm
Weight62 g
Packaging data
Package depth100 mm
Package width152 mm
Package height30 mm
Package weight109 g
Packaging content
User guideYes
Interface adapters includedUSB Type-A male - USB Type-C female
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)20 - 85%
Indication
LED indicatorsYes
Ethernet LAN features
LED indicatorsYes
Other features
Mean time between failures (MTBF)129956 h
ChipsetASMedia - ASM2362
Logistics data
Master (outer) case width485 mm
Master (outer) case length325 mm
Master (outer) case height230 mm
Products per master (outer) case60 pc(s)
