SKU: E3SUPS20KHB  |   Brand: APC

APC Easy 3S uninterruptible power supply (UPS) Double-conversion (Online) 20 kVA 20000 W

SKU: E3SUPS20KHB  |   Brand: APC

APC Easy 3S uninterruptible power supply (UPS) Double-conversion (Online) 20 kVA 20000 W

3 in stock

£4,758.34 ex. VAT

Figures are exclusive of VAT.



APC Easy 3S. UPS topology: Double-conversion (Online), Output power capacity: 20 kVA, Output power: 20000 W. Battery technology: Sealed Lead Acid (VRLA), Battery voltage: 220 V. Form factor: Tower, Product colour: White, Display type: LED. Width: 380 mm, Depth: 928 mm, Height: 1400 mm. Output voltage: 400 V

Product colour White
Output power 18000W to 32000W
UPS topology Double-conversion (Online)
Output power capacity 16000VA to 40000VA
Form factor Tower
Weight 158,000.00kg

Power
Input power factor0.99
Output power20000 W
Input operation voltage (min)304 V
Input operation voltage (max)477 V
Output operation voltage (min)380 V
Output operation voltage (max)415 V
Maximum current37 A
Output voltage Total Harmonic Distortion (THD)3%
Input current Total Harmonic Distortion (THD)3%
Output power capacity20 kVA
Performance
UPS topologyDouble-conversion (Online)
WaveformPure sine
Number of output phases3
Number of input phases3
Features
Output frequency50/60 Hz
UPS topologyDouble-conversion (Online)
WaveformPure sine
Number of output phases3
Number of input phases3
Input power factor0.99
Output power20000 W
Input operation voltage (min)304 V
Input operation voltage (max)477 V
Output operation voltage (min)380 V
Output operation voltage (max)415 V
Maximum current37 A
Output voltage Total Harmonic Distortion (THD)3%
Input current Total Harmonic Distortion (THD)3%
Output power capacity20 kVA
Input frequency45/65 Hz
Battery
Number of batteries supported3
Battery voltage220 V
Battery technologySealed Lead Acid (VRLA)
Design
International Protection (IP) codeIP20
Form factorTower
Product colourWhite
CertificationCE, EAC, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE, REACH
Display typeLED
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 40 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 999.9 m
Non-operating altitude0 - 15000 m
Technical details
Output voltage400 V
Output frequency50/60 Hz
Harmonized System (HS) code85078000
Compliance certificatesRoHS
Weight & dimensions
Package width563 mm
Package depth1014 mm
Package height1640 mm
Weight122 kg
Width380 mm
Package weight158 kg
Height1400 mm
Depth928 mm
Packaging data
Quick installation guideYes
Package width563 mm
Package depth1014 mm
Package height1640 mm
Package weight158 kg
Logistics data
Harmonized System (HS) code85078000
Certificates
CertificationCE, EAC, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE, REACH
Other features
Output voltage400 V
Packaging content
Quick installation guideYes
