| Ethernet LAN features |
|---|
| Ethernet WAN | Yes |
| Ethernet LAN interface type | 10 Gigabit Ethernet |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000,2500,10000 Mbit/s |
| Auto MDI/MDI-X | Yes |
| Cabling technology | 10/100/1000/2500/5000/10000Base-T |
| DSL features |
|---|
| DSL WAN | Yes |
| ADSL2+ | Yes |
| VDSL2 | Yes |
| Network |
|---|
| Wake-on-LAN ready | Yes |
| Routing protocols | BGP, OSPF, RIP-1, RIP-2, RIPng |
| Network address translation (NAT) | Yes |
| Guest access | Yes |
| Ethernet LAN interface type | 10 Gigabit Ethernet |
| Ethernet LAN | Yes |
| VPN tunnels quantity | 50 |
| Port forwarding | Yes |
| Flow control support | Yes |
| Ethernet LAN data rates | 1000,2500,10000 Mbit/s |
| Automatic channel selection | Yes |
| Auto MDI/MDI-X | Yes |
| Cabling technology | 10/100/1000/2500/5000/10000Base-T |
| Port triggering | Yes |
| USB sharing | Yes |
| VPN Passthrough | Yes |
| Static route | Yes |
| SSID-based VLAN assignment | Yes |
| Policy-based routing | Yes |
| Multicast support | Yes |
| Load balancing system | Yes |
| Dynamic DNS (DDNS) | Yes |
| Ping check | Yes |
| Internet connection backup | Yes |
| Protocols |
|---|
| DMZ support | Yes |
| Universal Plug and Play (UPnP) | Yes |
| Routing protocols | BGP, OSPF, RIP-1, RIP-2, RIPng |
| DHCP server | Yes |
| DHCP client | Yes |
| IPv4 & IPv6 features | Dual stack IPv4/IPv6 |
| Management features |
|---|
| Universal Plug and Play (UPnP) | Yes |
| WPS push button | Yes |
| Web-based management | Yes |
| Wake-on-LAN ready | Yes |
| Reset button | Yes |
| Quality of Service (QoS) support | Yes |
| Bandwidth control | Yes |
| Web-based setup wizard | Yes |
| Intelligent Mesh technology | Yes |
| MU-MIMO technology | Yes |
| MIMO | Yes |
| Number of data streams | 4x4 |
| Traffic statistics | Yes |
| Cloud-managed | Yes |
| Command-line interface (CLI) | Yes |
| Backup function | Yes |
| Security |
|---|
| VPN tunnels quantity | 50 |
| URL filtering | Yes |
| System event log | Yes |
| Security algorithms | 3DES, AES, DES, HTTPS, IPSec, OWE, SSH, WEP, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal |
| Port-based Network Access Control (PNAC) | Yes |
| Network address translation (NAT) | Yes |
| MAC address filtering | Yes |
| IP address filtering | Yes |
| Guest access | Yes |
| Firewall | Yes |
| DoS attack prevention | Yes |
| DMZ support | Yes |
| Filtering | Yes |
| Schedule access | Yes |
| Parental control | Yes |
| Stateful Packet Inspection (SPI) | Yes |
| Access Control List (ACL) | Yes |
| DDoS protection | Yes |
| IGMP snooping | Yes |
| Performance |
|---|
| Firmware upgradeable | Yes |
| Automatic channel selection | Yes |
| Web-based setup wizard | Yes |
| Packaging content |
|---|
| Package type | Box |
| Quick start guide | Yes |
| Cables included | LAN (RJ-45), Phone (RJ-11) |
| AC adapter included | Yes |
| Antenna included | Yes |
| Packaging content | Vigor 2867be router 2x Detachable Wireless LAN Antennas Quick Start Guide RJ-11 DSL Cable RJ-45 Network Cable DC 12V Power Supply with UK Plug |
| WAN connection |
|---|
| Ethernet WAN | Yes |
| DSL WAN | Yes |
| Wireless LAN features |
|---|
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| WLAN data transfer rate (max) | 7200 Mbit/s |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Wi-Fi standards | Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 7 (802.11be) |
| Ports & interfaces |
|---|
| USB port | Yes |
| USB 2.0 ports quantity | 2 |
| RJ-11 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 4 |
| DC-in jack | Yes |
| Design |
|---|
| Product type | Rack/wall router |
| Wall mountable | Yes |
| On/off switch | Yes |
| Housing material | Plastic |
| Country of origin | Taiwan |
| Product colour | White |
| Indication light | Yes |
| Rack capacity | 1U |
| Certificates |
|---|
| PSTI certified | Yes |
| Antenna |
|---|
| Antenna design | Internal & external |
| Detachable antenna(s) | Yes |
| Antenna connector type | RP-SMA |
| Antenna type | 4x4 |
| Features |
|---|
| Firmware upgradeable | Yes |
| Operating system installed | DrayOS 5 |
| Power |
|---|
| External power adapter | Yes |
| Operational conditions |
|---|
| Storage temperature (T-T) | -25 - 70 °C |
| Operating temperature (T-T) | 0 - 45 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions |
|---|
| Width | 241 mm |
| Weight | 1.15 kg |
| Height | 44 mm |
| Depth | 210 mm |
| Packaging data |
|---|
| Quick start guide | Yes |
| Package type | Box |
| Cables included | LAN (RJ-45), Phone (RJ-11) |
| AC adapter included | Yes |
| Antenna included | Yes |
| Technical details |
|---|
| Warranty period | 2 year(s) |
| PSTI certified | Yes |
| Logistics data |
|---|
| Country of origin | Taiwan |
| Warranty period | 2 year(s) |
