TP-Link Omada AX3000 Indoor/Outdoor WiFi 6 Access Point

SKU: EAP650 D30-OUTDOOR | Brand: TP-LINK

TP-Link Omada AX3000 Indoor/Outdoor WiFi 6 Access Point

41 in stock

£176.23 ex. VAT

Figures are exclusive of VAT.

+ Description

AX3000 Indoor/Outdoor WiFi 6 Access Point

Superior WiFi 6 Speeds: 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz.
Directional Ultra-Range Coverage: Equipped with built-in high-gain directional antennas to deliver precise and extended coverage.
Ideal for Warehouses and Outdoor Scenes: Features an IP68 waterproof enclosure with -30°C to +70°C operating range.
802.11k/v/r Seamless Roaming: Ensures uninterrupted connectivity for AGVs and handheld scanners.
Flexible Deployment: Supports 802.3at PoE and Omada Mesh technology.
Centralized Cloud Management: Control everything from a single interface anywhere via the Omada app or Web UI.

Designed for Warehouses

The EAP650 D30-Outdoor features a durable, fully sealed IP68 weatherproof enclosure, making it dustproof and capable of withstanding submersion in water. It is ideal for warehouse environments.

Elevate WiFi Experience for Shelf Areas with Directional Antennas

Equipped with 4x built-in dual-band directional antennas with high gain to ensure the optimal WiFi experience ideal for precise and extended coverage.*

Recommended Installation Height: 13 ft / 4 m

Recommended Coverage Length: 262 ft / 80 m

Directional Antennas for Ultra-Range Coverage in Outdoor Scenarios

2.4 GHz up to 1181 ft /360 m*

5 GHz up to 2953 ft /900 m*

*Based on field tests in an open, outdoor, and unobstructed environment. The number listed here is the maximum distance of one EAP650 D30-Outdoor which the client's signal strength is ≥ -75 dBm. The real transmission range and recommended coverage may vary, according to the environment, receiving device, etc.

Stay Smooth with Seamless Roaming

Ensure users enjoy uninterrupted steaming when moving around by switching clients automatically to the access points with the optimal signals.

+ Tech Specs

5 GHz	Y
2.4 GHz	Y

Attributes

Data transmission
Ethernet LAN data rates	10,100,1000 Mbit/s
Maximum data transfer rate	3000 Mbit/s
Performance
2.4 GHz	Yes
5 GHz	Yes
Automatic channel selection	Yes
Web-based management	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Maximum data transfer rate	3000 Mbit/s
MIMO type	Multi User MIMO
MIMO	Yes
Band steering	Yes
Airtime Fairness (ATF)	Yes
Remote Authentication Dial-In User Service (RADIUS)	Yes
Features
6 GHz	No
2.4 GHz	Yes
5 GHz	Yes
Automatic channel selection	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Maximum data transfer rate	3000 Mbit/s
Bluetooth	Yes
MIMO type	Multi User MIMO
MIMO	Yes
Band steering	Yes
Airtime Fairness (ATF)	Yes
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Maximum data transfer rate (5 GHz)	2402 Mbit/s
Security
Security algorithms	SNMP, SNMPv2, SNMPv3
MAC address filtering	Yes
Remote Authentication Dial-In User Service (RADIUS)	Yes
Management features
Web-based management	Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
Power
Power over Ethernet (PoE)	Yes
AC input voltage	48 V
Power over Ethernet (PoE) type supported	Passive PoE
Design
Placement	Ceiling, Wall
Product colour	White
Antenna
Antenna type	Internal
Technical details
Vertical beam width	30°
Horizontal beam width	30°
Weight & dimensions
Width	207.5 mm
Depth	58 mm
Height	230 mm
Packaging data
Quick start guide	Yes
Mounting kit	Yes
Packaging content
Quick start guide	Yes
Mounting kit	Yes
Quantity per pack	1 pc(s)
Other features
Vertical beam width	30°
Horizontal beam width	30°
Logistics data
Quantity per pack	1 pc(s)
