TP-Link Omada EAP727 wireless access point 5012 Mbit/s White Power over Ethernet (PoE)

SKU: EAP727 | Brand: TP-LINK

TP-Link Omada EAP727 wireless access point 5012 Mbit/s White Power over Ethernet (PoE)

0 in stock

£124.05 ex. VAT

Figures are exclusive of VAT.

+ Description

Optimized Wired Performance with 2.5G PoE+ Port
With a 2.5 Gigabit Ethernet Port, EAP727 delivers remarkable multi-gigabit performance for higher bandwidth and faster Wi-Fi. Compatibility with 802.3at PoE is ideal for flexible deployment.

+ Tech Specs

2.4 GHz	Y
5 GHz	Y
Family	Omada

Attributes

Data transmission
Ethernet LAN data rates	10,100,1000,25000 Mbit/s
Maximum data transfer rate	5012 Mbit/s
Performance
Full duplex	Yes
2.4 GHz	Yes
5 GHz	Yes
Wireless isolation	Yes
Wi-Fi Multimedia (WMM)/(WME)	Yes
Auto MDI/MDI-X	Yes
Country of origin	China
Reset button	Yes
Firmware upgradeable	Yes
Number of users	510 user(s)
Web-based management	Yes
VLAN support	Yes
Rate limiting	Yes
Quality of Service (QoS) support	Yes
Number of WLAN connections (max)	16
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11ax
Ethernet LAN data rates	10,100,1000,25000 Mbit/s
Channel bandwidth	160 MHz
Maximum data transfer rate	5012 Mbit/s
MIMO type	Multi User MIMO
MIMO	Yes
Wi-Fi roaming	Yes
Band steering	Yes
Airtime Fairness (ATF)	Yes
Remote Authentication Dial-In User Service (RADIUS)	Yes
Built-in processor	Yes
Network
Number of users	510 user(s)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11ax
Bandwidth
Channel bandwidth	160 MHz
Management features
VLAN support	Yes
Rate limiting	Yes
Quality of Service (QoS) support	Yes
Firmware upgradeable	Yes
Web-based management	Yes
Command-line interface (CLI)	Yes
Traffic statistics	Yes
Cloud-managed	Yes
Backup function	Yes
Features
6 GHz	No
Full duplex	Yes
2.4 GHz	Yes
5 GHz	Yes
Wireless isolation	Yes
Wi-Fi Multimedia (WMM)/(WME)	Yes
Auto MDI/MDI-X	Yes
Number of users	510 user(s)
VLAN support	Yes
Rate limiting	Yes
Quality of Service (QoS) support	Yes
Number of WLAN connections (max)	16
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11ax
Ethernet LAN data rates	10,100,1000,25000 Mbit/s
Channel bandwidth	160 MHz
Cabling technology	10/100/1000/2500Base-T
Maximum data transfer rate	5012 Mbit/s
Bluetooth	Yes
Bluetooth version	5.2
Transmitting power (FCC)	27 dBm
Transmitting power (CE)	30 dBm
Fast roaming	Yes
Dynamic Frequency Selection (DFS)	Yes
Duplex mode auto-negotiation	Yes
MIMO type	Multi User MIMO
MIMO	Yes
Wi-Fi roaming	Yes
Band steering	Yes
Airtime Fairness (ATF)	Yes
Maximum data transfer rate (2.4 GHz)	688 Mbit/s
Maximum data transfer rate (5 GHz)	4324 Mbit/s
Bluetooth Low Energy (BLE)	Yes
BeamForming	Yes
Spatial streams	5
Number of simultaneously connected devices (max)	510
Coverage area	185 m²
Wireless meshing	Yes
Maximum Tx power (2.4 GHz)	20 dBmW
Maximum Tx power (5 GHz)	30 dBmW
Number of guest networks (2.4 GHz)	8
Built-in processor	Yes
Security
Number of SSID supported	16
Security algorithms	WPA, WPA3, WPA2
MAC address filtering	Yes
Access Control List (ACL)	Yes
Remote Authentication Dial-In User Service (RADIUS)	Yes
Service Set Identifier (SSID) features	Multiple SSIDs
Guest access	Yes
Schedule access	Yes
Protocols
Management protocols	NMP v1, SNMP v2c, SNMP v3, SSH
Supported network protocols	IPv4, IPv6, LLDP, mDNS
DHCP client	Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
DC-in jack	Yes
Cabling technology	10/100/1000/2500Base-T
Power
Power consumption (max)	15.6 W
Power supply	18 W
Power over Ethernet (PoE)	Yes
Input current	1.5 A
DC voltage range	12 V
Design
Placement	Ceiling, Wall
Country of origin	China
Product colour	White
Reset button	Yes
LED indicators	Yes
Antenna
Antenna type	Internal
Antennas quantity	5
Antenna gain level (max)	6 dBi
Antenna direction type	Omni-directional
Antenna features	Integrated antenna
Technical details
Reset button	Yes
Firmware upgradeable	Yes
Number of WLAN connections (max)	16
Compliance certificates	CE, JRF, ICES
Wall mountable	Yes
Ethernet LAN	Yes
Processor
Built-in processor	Yes
Certificates
Compliance certificates	CE, JRF, ICES
Indication
LED indicators	Yes
Software
Access Control List (ACL)	Yes
Fast roaming	Yes
Dynamic Frequency Selection (DFS)	Yes
Duplex mode auto-negotiation	Yes
Weight & dimensions
Width	160 mm
Depth	160 mm
Weight	470 g
Height	36.7 mm
Packaging content
Quantity per pack	1 pc(s)
Operational conditions
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90%
Operating altitude	0 - 2000 m
Non-operating altitude	0 - 2000 m
Logistics data
Country of origin	China
Quantity per pack	1 pc(s)
